AM

Ø 36-58mm magnetic encoder

AM36 and AM58 series’ encoders use magnetic technology and output up to 12 bit resolution through binary code. These encoders can have different signal modifications: incremental, serial interface, commutation.

Mechanical data

AM36 AM58
Maximum shaft speed 10000 rpm 12000 rpm
Maximum shaft load axial: 5 N
radial: 10 N
axial: 10 N
radial: 20 N
Starting torque at 20°C < 0.002 Nm < 0.01 Nm
Rotor moment of inertia < 2 gcm2 < 15 gcm2
Protection (IEC 529) IP64 IP67
Maximum weight without cable 0.07 kg 0.25 kg
Operating temperature -25…+85°C -25…+85°C
Storage temperature -40…+125°C -40…+125°C
Maximum humidity (non-condensing) 98% 98%
Permissible vibration (55 to 2000 Hz) < 100 m/s² < 100 m/s²
Permissible shock (11 ms) < 300 m/s² < 300 m/s²
