AN Ø70mm absolute encoder
The AN Ø70 mm Absolute Encoder is a high-resolution, single-turn optical encoder designed for precision motion control. It features a 22-bit BiSS-C interface for accurate digital output. The encoder uses optical reflectance sensors arranged at 180°, which eliminates mechanical errors such as shaft runout through advanced electronic compensation.
This encoder ensures reliable performance in demanding industrial and automation applications, even under vibration and shock conditions.
Key Features
-
Diameter: Ø70 mm
-
High resolution: 22-bit singleturn measurement
-
BiSS-C interface for digital communication
-
Dual optical sensors arranged at 180° for mechanical error compensation
-
Maximum shaft speed: 4,000 rpm
-
Extremely low rotor inertia: <30×10⁻⁶ g·cm²
-
Wide operating temperature range: –40 to +100 °C
-
Compact and lightweight: 0.05 kg
Mechanical & Environmental Data
| Parameter | Specification |
|---|---|
| Maximum shaft speed | 4,000 rpm |
| Permissible axial motion of measured shaft | 0.03 mm |
| Permissible radial runout | 0.03 mm |
| Rotor moment of inertia | < 30×10⁻⁶ g·cm² |
| Protection (IEC 529) | IP00 |
| Maximum weight without cable | 0.05 kg |
| Operating temperature | –40…+100 °C |
| Storage temperature | –40…+100 °C |
| Maximum humidity | 98% non-condensing |
| Permissible vibration (55–2000 Hz) | ≤ 100 m/s² |
| Permissible shock (11 ms) | ≤ 200 m/s² |
