Zero Cogging Direct Drive Motors for Exceptionally Smooth Motion
Designed with ZeroCog™ slotless motor technology from Applimotion, the Agility Series enables OEMs to achieve extremely smooth and highly accurate motion profiles using flexible and easy-to-integrate motor components. Ideally suited for scanning, pointing, measuring and cutting applications that require extremely smooth velocity control and highly accurate positioning, the Agility Series delivers best-in-class torque ripple and zero cogging.
- Zero cogging and low torque ripple for extremely smooth velocity control and low vibration
- Slotless magnetic design and direct drive technology enable highly accurate position control
- High torque density in low-profile form factors enables small footprint
- Large through hole for convenient routing of cables, optics, sensing technologies, and other system elements
- High mechanical stiffness and low rotor inertia for efficient control of highly dynamic axes
- Easy integration into system design
- Compatible with a wide range of drives and controllers
Specifications of Agility Series – UTS
| Continuous Torque | 0.04 to 9.06 Nm |
| Peak Torque | 0.123 to 27.20 Nm |
| Diameter (Stator OD) | 18.97 to 222.25 mm |
| Through Hole (Rotor ID) | 5.00 to 190.50 mm |
| Stator Length | 19.81 to 62.27 mm |
| Pole Count | 6 to 64 |
